63T Rubber Sole Making Machine Vulcanizing Press Machine CE ISO

    Buy cheap 63T Rubber Sole Making Machine Vulcanizing Press Machine CE ISO from wholesalers

    Buy cheap 63T Rubber Sole Making Machine Vulcanizing Press Machine CE ISO from wholesalers
    • Buy cheap 63T Rubber Sole Making Machine Vulcanizing Press Machine CE ISO from wholesalers
    • Buy cheap 63T Rubber Sole Making Machine Vulcanizing Press Machine CE ISO from wholesalers
    • Buy cheap 63T Rubber Sole Making Machine Vulcanizing Press Machine CE ISO from wholesalers
    • Buy cheap 63T Rubber Sole Making Machine Vulcanizing Press Machine CE ISO from wholesalers
    • Buy cheap 63T Rubber Sole Making Machine Vulcanizing Press Machine CE ISO from wholesalers

    63T Rubber Sole Making Machine Vulcanizing Press Machine CE ISO

    Ask Lasest Price
    Brand Name : HUALONG
    Certification : CE ISO
    Supply Ability : 10 Set/Sets per Month
    Price : $10,000.00
    Model Number : XLB600*600
    • Product Details
    • Company Profile

    63T Rubber Sole Making Machine Vulcanizing Press Machine CE ISO

    Rubber Sole Vulcanizing Machine, Rubber Sole Making Machine
    Rubber Sole Making Machine Rubber Vulcanizing Press Machine: 63T
    1. Pressure : 63T
    2. Plate size: 400*400mm
    3. Working Layer: 2 working layers
    4. Structure: column type
    5. Daylight gap:250mm
    6. Piston stroke: 400mm
    7. Control mode: Siemens PLC automatic opening and closing.
    TypeXLB240×240×2XLB350×350×2XLB400×400×2XLB500×500×2XLB600×600×2/4XLB700×700×2XLB750×850×2/4XLB900×900×2Q
    Total pressure (MN)0.150.250.50.631.001.201.602.00
    Plate distance(mm)125125125125125125200300
    Working layer number22222-422-42
    Unit area pressure of hot plate(Mpa)2.602.043.132.522.772.452.512.47
    Plunger stroke(mm)250250250250250/400250400400
    Heating modeelectricityelectricityelectricity/steamelectricity/steamelectricity/steamsteamelectricity/steamsteam
    Main motor power (KW)2.22.22.22.22.22.235.5
    Overall dimension (L×W×H) (mm)1200×350×13001400×480×13801600×500×14801750×600×15401880×720×16802000×850×17502250×1200×22001400×900×2400
    Frame formPostPostPostPostPostPostFrameFrame
    Accept customized requirements and offer free technical support.
    63T Rubber Sole Making Machine Vulcanizing Press Machine CE ISO
    Related Products
    Frame Type Rubber Vulcanizing Press Machine -------Russia and U.S customer
    Improved Rubber Car Mat Making Machine---South Africa customer
    1. open and out mold in 4 directions
    2. each time produce 4 pieces, high production efficiency
    63T Rubber Sole Making Machine Vulcanizing Press Machine CE ISO

    Convery Belt Production Line--------Indonesia Customer

    63T Rubber Sole Making Machine Vulcanizing Press Machine CE ISO

    Inner Tube Production Line---------------- India customer

    63T Rubber Sole Making Machine Vulcanizing Press Machine CE ISO

    QINGDAO SHENGHUALONG RUBBER MACHINERY was established in 1967,have employee more than five hundreds,
    manufacturing for rubber machine and laminating machine.
    As a rubber machinery manufacturer ,Hangsen has land for more than 50000 square meters, with a total assets of more than USD 100million, more than 500 employees, and 60 mechanical engineers,

    The company is one of the largest private enterprises engaging in professional produce rubber machine .
    We 8 meters gantry type milling machine,
    TK6913B CNC boring and milling machine
    TPX6213 floor boring
    TPX6113 milling and boring machine
    Vertical machining center
    CY-K630 CNC lathe
    2.5 Meters vertical lathe and other large advanced processing equipment
    We mainly produce following machinery.
    Radial tire equipment
    XK-660 Rubber open mixing mill
    42 to 65.5 inch double mold vulcanizing machine
    75-105 inch single mold vulcanizing machine
    Internal mixer series, Rubber mixing mill series, Extrusion and filter series
    Tyre tube, flap, inner tube plate vulcanizing machine
    Waste tire recycling line
    Rubber reclaim sheet line and so on,
    We can also design and manufacture for various non-standard rubber machinery and equipment according to the customers requirement.
    Our company always follows the market concept of “Market demand first , Customer first.
    Till now,We have exported to more than 40 countries,enjoy a good reputation in the world market.
