Gym Rubber Floor Tiles Making Machine Plate Vulcanizing Press 5.5KW

    Buy cheap Gym Rubber Floor Tiles Making Machine Plate Vulcanizing Press 5.5KW from wholesalers

    Buy cheap Gym Rubber Floor Tiles Making Machine Plate Vulcanizing Press 5.5KW from wholesalers
    • Buy cheap Gym Rubber Floor Tiles Making Machine Plate Vulcanizing Press 5.5KW from wholesalers
    • Buy cheap Gym Rubber Floor Tiles Making Machine Plate Vulcanizing Press 5.5KW from wholesalers
    • Buy cheap Gym Rubber Floor Tiles Making Machine Plate Vulcanizing Press 5.5KW from wholesalers
    • Buy cheap Gym Rubber Floor Tiles Making Machine Plate Vulcanizing Press 5.5KW from wholesalers
    • Buy cheap Gym Rubber Floor Tiles Making Machine Plate Vulcanizing Press 5.5KW from wholesalers
    • Buy cheap Gym Rubber Floor Tiles Making Machine Plate Vulcanizing Press 5.5KW from wholesalers

    Gym Rubber Floor Tiles Making Machine Plate Vulcanizing Press 5.5KW

    Ask Lasest Price
    Certification : CE ISO
    Supply Ability : 10 Set/Sets per Month
    Price : $15,000.00/sets >=1 sets
    Brand Name : HUALONG
    Model Number : XLB
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Gym Rubber Floor Tiles Making Machine Plate Vulcanizing Press 5.5KW

    Rubber Gym Flooring Rubber Tiles, Rubber Floor Tiles Machine
    Frame plate
    The material is made of Q235A steel plate with overall numerical control cutting, and the surface is sandblasted.
    Oil cylinder
    The material of the oil cylinder is high quality QT500-7, ductile iron QT-500 is passivated after aging, or forging material is used, tensile strength ≥50kgf/mm
    Gym Rubber Floor Tiles Making Machine Plate Vulcanizing Press 5.5KW
    The plunger is made of LG-P chilled alloy material, which has high surface hardness and is not easy to wear. The depth of the chilled layer is 8-15mm and the hardness is HRC 70 degrees, which improves the overall service life of the plunger.
    Gym Rubber Floor Tiles Making Machine Plate Vulcanizing Press 5.5KW
    Die entry and exit rail (if equipped): The sliding surface is made of S50# steel, and has been heat-treated to a hardness of HRC 55-58. It has a long wear-resistant life and is equipped with a bearing design to make the entry and exit molds slide stably.
    Gym Rubber Floor Tiles Making Machine Plate Vulcanizing Press 5.5KW
    Hydraulic system: The main hydraulic components adopt well-known brands such as Taiwan Qiyang, Beijing Huade, Yuyan, etc., easy to buy and replace, reasonable layout, and easy to maintain and repair.
    Gym Rubber Floor Tiles Making Machine Plate Vulcanizing Press 5.5KW
    Electrical system: The main PLC electrical components of this machine adopt Mitsubishi's internationally well-known brands. The electrical device has the advantages of small size, compact structure, fatigue resistance, and is suitable for continuous high-strength work.
    Gym Rubber Floor Tiles Making Machine Plate Vulcanizing Press 5.5KW
    Heat insulation board: The heat insulation board adopts high-quality calcium silicate board, with a pressure resistance of 3.5Mpa or more, and a heat insulation coefficient of 0.031.
    Item
    XLB-1200*1200*2 Rubber Tile Making Machine
    Total Pressure
    MN
    1.00
    Hot Plate Size
    MM
    1200*1200
    Plate thickness
    MM
    60
    Plate clearance
    MM
    200
    Working Layer
    Layer
    2
    Hot plate quantity
    Piece
    4
    Piston stroke
    MM
    200
    Piston quantity
    Set
    4*2 stes
    Heating mode
    Electrical heating
    Structure mode
    Column type
    Operation system
    Automatic control
    Working pressure
    Mpa
    0.66
    Working power
    KW
    5.5

    Gym Rubber Floor Tiles Making Machine Plate Vulcanizing Press 5.5KW

    QINGDAO SHENGHUALONG RUBBER MACHINERY was established in 1967,have employee more than five hundreds,
    manufacturing for rubber machine and laminating machine.
    As a rubber machinery manufacturer ,Hangsen has land for more than 50000 square meters, with a total assets of more than USD 100million, more than 500 employees, and 60 mechanical engineers,

    The company is one of the largest private enterprises engaging in professional produce rubber machine .
    We 8 meters gantry type milling machine,
    TK6913B CNC boring and milling machine
    TPX6213 floor boring
    TPX6113 milling and boring machine
    Vertical machining center
    CY-K630 CNC lathe
    2.5 Meters vertical lathe and other large advanced processing equipment
    We mainly produce following machinery.
    Radial tire equipment
    XK-660 Rubber open mixing mill
    42 to 65.5 inch double mold vulcanizing machine
    75-105 inch single mold vulcanizing machine
    Internal mixer series, Rubber mixing mill series, Extrusion and filter series
    Tyre tube, flap, inner tube plate vulcanizing machine
    Waste tire recycling line
    Rubber reclaim sheet line and so on,
    We can also design and manufacture for various non-standard rubber machinery and equipment according to the customers requirement.
    Our company always follows the market concept of “Market demand first , Customer first.
    Till now,We have exported to more than 40 countries,enjoy a good reputation in the world market.
