    XPG600 Batch Off Rubber Cooling Machine 600mm Rubber Sheet Cooling Line

    Ask Lasest Price
    Brand Name : HUALONG
    Model Number : XPG-600
    Certification : ISO,CE
    Price : USD40000
    Supply Ability : 30 sets per month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    XPG600 Batch Off Rubber Cooling Machine 600mm Rubber Sheet Cooling Line

    Batch Off Cooler Machine For Rubber Process Machine


    1. Rubber sheet cooling line adopts steel conveying rollers, equipped with printer and slitter. The take-off and lifting device are driven by a common AC inverter motor. The conveying speed is adjustable.
    2. The sheet is uniformly coated with the lubricator by dipping without polluting the environment. Its cooling effect is better than the spraying.
    3. The hanging up area is fully closed, which adopts the blower to blow the sheet at a slant. So it improves the air flowing direction and cooling effect.
    4. The robot in the take-off is advanced in China. The take-off can be controlled automatically.

    ModelXPG-600XPG-600XPG-800XPG-900
    Max. Rubber Sheet Width (mm)600600800900
    Rubber Sheet thickness (mm)4-102-124-106-12
    Temperature over room temperature after rubber sheet cooling (℃)1010155
    Linear Speed of taking-in conveyor (m/min)3-243-243-354-40
    Linear speed of sheet-hanging chain (m/min)0.8250.117-1.174-40
    Hanging height of the sheet hanging bar (m)1000-1500Net1000-15001400
    No. of cooling fans (set)122018-26
    Total power (KW)13.728.818-34
    Overall Dimension(mm)L14251680026630
    W450047003500
    H340535205630

    XPG600 Batch Off Rubber Cooling Machine 600mm Rubber Sheet Cooling LineXPG600 Batch Off Rubber Cooling Machine 600mm Rubber Sheet Cooling Line

    COMPANY INTRODUCTION

    QINGDAO SHENGHUALONG RUBBER MACHINERY was established in 1967,have employee more than five hundreds,
    manufacturing for rubber machine and laminating machine.
    As a rubber machinery manufacturer ,Hangsen has land for more than 50000 square meters, with a total assets of more than USD 100million, more than 500 employees, and 60 mechanical engineers,

    The company is one of the largest private enterprises engaging in professional produce rubber machine .
    We 8 meters gantry type milling machine,
    TK6913B CNC boring and milling machine
    TPX6213 floor boring
    TPX6113 milling and boring machine
    Vertical machining center
    CY-K630 CNC lathe
    2.5 Meters vertical lathe and other large advanced processing equipment
    We mainly produce following machinery.
    Radial tire equipment
    XK-660 Rubber open mixing mill
    42 to 65.5 inch double mold vulcanizing machine
    75-105 inch single mold vulcanizing machine
    Internal mixer series, Rubber mixing mill series, Extrusion and filter series
    Tyre tube, flap, inner tube plate vulcanizing machine
    Waste tire recycling line
    Rubber reclaim sheet line and so on,
    We can also design and manufacture for various non-standard rubber machinery and equipment according to the customers requirement.
    Our company always follows the market concept of “Market demand first , Customer first.
    Till now,We have exported to more than 40 countries,enjoy a good reputation in the world market.
