    22KW Rubber Tire Grinder 40-60kg/H Scrap Tyre Powder Machine

    Ask Lasest Price
    Brand Name : HUALONG
    Supply Ability : 30 Set/Sets per Month
    Price : $8,300.00/sets >=1 sets
    Model Number : XMF-360
    Certification : ISO,CE
    Delivery Time : 40 days
    • Product Details
    • Company Profile

    22KW Rubber Tire Grinder 40-60kg/H Scrap Tyre Powder Machine

    High Capacity Tire Rubber Grinder Machine Tire Rubber Powder Recycling Line

    Structure and Principle

    1. The machine uses tungsten carbide as the milling surface of the milling disc, the milling disc base is made of special treated materials, crashing-proof, wearable, durable and good ductility;

    2. The whole machine adopts horizontal structure, most parts are CNC processed to ensure the installation accuracy;

    3. Compact structure, low power and vibration, easy operation and maintenance;

    4. The feeding system adopts ultra-red monitor controlled by PLC to maximum the output. The clearance between fixed and rotary discs are also controlled by PLC motors, which has greatly improved the quality and fineness of the rubber powder;

    5.Internal circulating water cooling system can ensure ideal temperature for the milling discs during production, the rubber powder will not get burned or sticky.

    22KW Rubber Tire Grinder 40-60kg/H Scrap Tyre Powder Machine
    22KW Rubber Tire Grinder 40-60kg/H Scrap Tyre Powder Machine
    22KW Rubber Tire Grinder 40-60kg/H Scrap Tyre Powder Machine
    Main technical paratmeters
    XMF-270
    XMF-330
    XMF-380
    XMF-420
    In-feed size(mesh)
    10-20
    10-20
    5-20
    5-20
    Output size (mesh)
    40-60 60-80 80-120
    40-60 60-80 80-120
    40-60 60-80 80-120
    40-60 60-80 80-120
    Capacity (kg/h)
    80-120 60-80 40-60
    120-150 90-110 50-60
    150-180 110-130 70-80
    170-210 130-150 80-100
    Power of main motor(KW)
    22
    30
    37
    45
    Power of in-feed motor(KW)
    1.5
    1.5
    1.5
    2.2
    Dimensions(mm)
    1800*1700*1550
    2050*1710*1600
    2100*1750*1620
    2200*1800*1900
    Weight(kg)
    2000
    2600
    2900
    3500
    22KW Rubber Tire Grinder 40-60kg/H Scrap Tyre Powder Machine
    22KW Rubber Tire Grinder 40-60kg/H Scrap Tyre Powder Machine

    QINGDAO SHENGHUALONG RUBBER MACHINERY was established in 1967,have employee more than five hundreds,
    manufacturing for rubber machine and laminating machine.
    As a rubber machinery manufacturer ,Hangsen has land for more than 50000 square meters, with a total assets of more than USD 100million, more than 500 employees, and 60 mechanical engineers,

    The company is one of the largest private enterprises engaging in professional produce rubber machine .
    We 8 meters gantry type milling machine,
    TK6913B CNC boring and milling machine
    TPX6213 floor boring
    TPX6113 milling and boring machine
    Vertical machining center
    CY-K630 CNC lathe
    2.5 Meters vertical lathe and other large advanced processing equipment
    We mainly produce following machinery.
    Radial tire equipment
    XK-660 Rubber open mixing mill
    42 to 65.5 inch double mold vulcanizing machine
    75-105 inch single mold vulcanizing machine
    Internal mixer series, Rubber mixing mill series, Extrusion and filter series
    Tyre tube, flap, inner tube plate vulcanizing machine
    Waste tire recycling line
    Rubber reclaim sheet line and so on,
    We can also design and manufacture for various non-standard rubber machinery and equipment according to the customers requirement.
    Our company always follows the market concept of “Market demand first , Customer first.
    Till now,We have exported to more than 40 countries,enjoy a good reputation in the world market.
