    Open Rubber Mixing Mill XK450 Two Roll Mixing Mill For Rubber

    Ask Lasest Price
    Brand Name : HUALONG
    Certification : CE
    Supply Ability : 10 Set/Sets per Month
    Price : $25,000.00/sets >=1 sets
    Model Number : XK450
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Open Rubber Mixing Mill XK450 Two Roll Mixing Mill For Rubber

    Open Rubber Mixing Mill XK450 Two Roll Mill Rubber Mixing Machine

    Equipment application and operation requirements


    1. Main application: mixing mill is mainly used for rubber compound warming, mixing &sheeting, as well as raw rubber plasticating, mixing &sheeting.
    2. Operation requirements

    A. running environment: altitude<1000m,
    temperature: 5℃-40℃, max. relative humidity 95%
    B. Power supply: AC380V, 50Hz, 3-phase
    C. Cooling water pressure: 2-0.4Mpa
    Cooling water temperature: ﹤25℃±3℃
    Type
    XK-160
    XK-230
    XK-250
    XK-300
    XK- 360
    Working diameter of rolls (mm)
    160230250300360
    Working Length of rolls (mm)
    320600620750900
    Front roll surface speed (m/min)
    8.9510.2114.115.116.25
    Friction ratio
    1:1.351:1.19
    1:1.17
    1:1.251:1.25
    Max. nip (mm)
    4.5781010
    Capacity per batch (kg)
    1-26-108-1515-2020-25
    Motor power (KW)
    5.51518.52230
    Size (L*W*H) (mm)
    1380*850*1320
    2800*1200*1120
    3400*1500*1500
    2450*1500*1550
    3780*1850*1750
    Type
    XK-400
    XK-450
    XK-560
    XK-550B
    XK-660
    Working diameter of rolls (mm)
    400
    450560/510550660
    Working Length of rolls (mm)
    10001200153015002130
    Front roll surface speed (m/min)
    18.6524.2627.7227.9428.6
    Friction ratio
    1:1.27
    1:1.271:1.21:1.221:1.24
    Max. nip (mm)
    1015151515
    Capacity per batch (kg)
    18-3525-5035-5050-60165
    Motor power (KW)
    375590110245
    Size (L*W*H) (mm)
    4350*1850*1785
    5200*2380*1840
    5845*2284*1978
    5878*2475*2045
    7455*3662*2080
    Open Rubber Mixing Mill XK450 Two Roll Mixing Mill For Rubber
    Open Rubber Mixing Mill XK450 Two Roll Mixing Mill For Rubber
    Open Rubber Mixing Mill XK450 Two Roll Mixing Mill For Rubber

    Open Rubber Mixing Mill XK450 Two Roll Mixing Mill For Rubber
    Open Rubber Mixing Mill XK450 Two Roll Mixing Mill For Rubber
    Open Rubber Mixing Mill XK450 Two Roll Mixing Mill For Rubber

    QINGDAO SHENGHUALONG RUBBER MACHINERY was established in 1967,have employee more than five hundreds,
    manufacturing for rubber machine and laminating machine.
    As a rubber machinery manufacturer ,Hangsen has land for more than 50000 square meters, with a total assets of more than USD 100million, more than 500 employees, and 60 mechanical engineers,

    The company is one of the largest private enterprises engaging in professional produce rubber machine .
    We 8 meters gantry type milling machine,
    TK6913B CNC boring and milling machine
    TPX6213 floor boring
    TPX6113 milling and boring machine
    Vertical machining center
    CY-K630 CNC lathe
    2.5 Meters vertical lathe and other large advanced processing equipment
    We mainly produce following machinery.
    Radial tire equipment
    XK-660 Rubber open mixing mill
    42 to 65.5 inch double mold vulcanizing machine
    75-105 inch single mold vulcanizing machine
    Internal mixer series, Rubber mixing mill series, Extrusion and filter series
    Tyre tube, flap, inner tube plate vulcanizing machine
    Waste tire recycling line
    Rubber reclaim sheet line and so on,
    We can also design and manufacture for various non-standard rubber machinery and equipment according to the customers requirement.
    Our company always follows the market concept of “Market demand first , Customer first.
    Till now,We have exported to more than 40 countries,enjoy a good reputation in the world market.
